Edmund Optics to provide demonstrations with new Dynamic Focus VZM lens at VISION 2014

Using its Dynamic Focus VZM lenses—which are debuting at VISION 2014—Edmund Optics will provide a live demonstration of circuit board inspection.

Oct 16th, 2014
Content Dam Vsd En Articles 2014 10 Edmund Optics To Provide Demonstrations With New Dynamic Focus Vzm Lens At Vision 2014 Leftcolumn Article Thumbnailimage File

Using its Dynamic Focus VZM lenses—which are debuting at VISION 2014—Edmund Optics will provide a live demonstration of circuit board inspection. The demonstration will show how variable depth imaging can benefit from a liquid lens. EO’s new lenses utilize an internal liquid lens and adjust focus over a 7X range, from 0.65X to 4.6X, while maintaining the zoom capabilities of the standard VZM zoom imaging lenses. The lenses feature a lockable iris, zoom control, and a rotatable mount. In addition, the focus on the lens can be controlled via the ruggedized 6-pin HIROSE connector and a USB port, while course magnification adjustments can be made manually. Software is also included for focus tuning.

VISION 2014 booth number: Booth E41 – Hall 1

To Learn More:


Contact: Edmund Optics
Headquarters: Barrington, NJ, USA
Product: Dynamic Focus VZM lenses
Key Features: Electronically adjust focus with integrated liquid lens, overcomes depth of field limitations, includes software for focus tuning.

What Edmund Optics says:

View more information on Edmund Optics lenses.
