European Southern Observatory creates first weather map of brown dwarf

The cryogenic infrared echelle spectrograph (CRIRES) instrument on the ESO’s Very Large Telescope was used to create the first ever weather map of the surface of Luhman 16B—the closest brown dwarf to Earth.

Content Dam Vsd En Articles 2014 02 European Southern Observatory Creates First Weather Map Of Brown Dwarf Leftcolumn Article Thumbnailimage File

The European Southern Observatory’s (ESO) Very Large Telescope (VLT) was used to create the first ever weather map of the surface of Luhman 16B—the closest brown dwarf to Earth.

Brown dwarfs fill the gap between giant gas planets like Jupiter, and faint stars, according to the ESO press release. These brown dwarfs do not contain enough mass to initiate nuclear fusion in their cores, and only glow slightly in infrared waves of light. Luhman 16B, also known as WISE J104915.57-531906.1B is a recently discovered brown dwarf that was discovered as a pair along with Luhman 16A, both of which are six light years away from the sun.

VLT’s cryogenic infrared echelle spectrograph (CRIRES) instrument was used to image the dwarfs, as well as map out dark and light features on Luhman 16B. CRIRES provides a resolving power of up to 100,000 between 0.95 μm and 5.38 μm. The instrument, according to the ESO, can be divided into four units:

  • Fore-optics, which provide field rotation, cold pupil and field stops, adaptive optics, and slit viewing
  • Prism pre-disperser, which isolates one echelle order and minimizes the total amount of liht entering into the high-resolution section
  • High-resolution section: Collimator, echelle, slitviewer camera, and detectors
  • Calibration unit outside the cryogenic environment which contains light sources for the flux/wavelength calibration and detector flat-fielding

CRIRES’ detector system uses five Raytheon 1,024 x 1,024 pixel InSb Aladdin arrays—one for the slitviewer camera and four in the spectrograph focal plane. Below are the main characteristics of the CRIRES instrument:

CRIRES captured images of Luhman 16B but also observed changing brightness and dark and light features that moved away or toward the observer, and by combining all of this information, the team was able to create a map of the dark and light patches of the surface. This information, according to Ian Crossfield of the Max Planck Institute for Astronomy, the lead author of a research paper on the project, opens up new doors for future research.

"Previous observations suggested that brown dwarfs might have mottled surfaces, but now we can actually map them," he said in the press release. "Soon, we will be able to watch cloud patterns form, evolve, and dissipate on this brown dwarf — eventually; exometeorologists may be able to predict whether a visitor to Luhman 16B could expect clear or cloudy skies."

View the ESO press release.
View more information on
CRIRES.
