ARM Cortex-based CPU module released by MYIR

Aug. 14, 2019
Cloud computing, machine vision, and flight navigation applications are intended applications for the MYC-CZU3EG.

The MYC-CZU3EG CPU module is powered by a Xilinx Zynq UltraScale+ ZU3EG MPSoC, with a 1.2 GHz quad-core ARM Cortex-A53 64-bit processor, a 600 MHz dual-core real-time ARM Cortex-R5 processor, a Mali400 embedded GPU, and FPGA fabric.

The module is 60 x 52 mm in size, has 4GB DDR4 memory, 4GB eMMC, and 128 MB QSPI Flash. The MYC-CZU3EG CPU also has integrated Ethernet PHY, USB PHY, and an Intel power module.

Two Samtec 0.5 mm pitch, 160-pin Razor Beam high-speed headers are available on the rear of the SoM for access to 156 user PL I/O pins, 4 PS GTR transceivers with 2 GTR reference dock inputs, 4 PL GTH transceivers with 1 GTH reference clock input, and PS MIOs.

The MYD-CZU3EG development board is designed to evaluate the MYC-CZU3EG CPU module. The development board has multiple interfaces including USB 3.0, GigE, DisplayPort, PCIe, SATA, and HDMI.

GET PRICING

To Learn More:

Contact: MYIR
Headquarters: Shenzhen, China
Product: MYC-CZU3EG CPU module
Key Features: Xilinx Zynq UltraScale+ ZU3EG MPSoC, 1.2 GHz quad-core ARM Cortex-A53 64-bit processor, 600 MHz dual-core real-time ARM Cortex-R5 processor, Mali400 embedded GPU, 4GB DDR4 memory, 4GB eMMC, 128 MB QSPI Flash,

What MYIR says: View more information on the MYC-CZU3EG CPU module.

Share your vision-related news by contacting Dennis Scimeca, Associate Editor, Vision Systems Design
