Frame grabbers from Euresys earn CoaXPress compliance certification

Coaxlink frame grabbers from Euresys have earned the official CoaXPress compliance certification, according to a company press release.

Content Dam Vsd En Articles 2015 02 Frame Grabbers From Euresys Earn Coaxpress Compliance Certification Leftcolumn Article Thumbnailimage File

Coaxlink frame grabbers from Euresys have earned the official CoaXPress compliance certification, according to a company press release.

The Coaxlink Mono, Duo, Quad and Quad G3 have successfully passed the official CoaXPress Product Certification Program, including the comprehensive Electrical Compliance Test. They have been verified as compliant with CoaXPress versions 1.1 and 1.0.

  • The Coaxlink Mono frame grabber features one CoaXPress connection (6.25 Gb/s), 10 digital I/O lines and a PCIe 2.0 (Gen 2) x4 bus (2 GB/s).
  • The Coaxlink Duo features two CoaXPress connections (12.5 Gb/s), 20 digital I/O lines, and a PCIe 2.0 (Gen 2) x4 bus (2 GB/s).
  • The Coaxlink Quad features four CoaXPress connections (25 Gb/s), 20 digital I/O lines, and a PCIe 2.0 (Gen 2) x4 bus (2 GB/s).
  • The Coaxlink Quad G3 features four CoaXPress connections (25 Gb/s), 20 digital I/O lines, and a PCIe 3.0 (Gen 3) x4 bus (3.9 GB/s).

The Coaxlink series targets applications requiring high data rates, high frame rates, consistent real-time timings but also longer cable length, and greater cable reliability and flexibility.

View more information on the Coaxlink series.
