Sensoray releases four-channel PCI Express frame grabber

Sensoray’s Model 810 PCI Express four-channel frame grabber with audio capture simultaneously capture four channels of analog NTSC/PAL video and four channels of stereo audio and is suitable for use in such applications as video surveillance, law enforcement, and traffic monitoring.

Content Dam Vsd Online Articles 2013 10 Sensoray Model 810 Copy

Sensoray’s Model 810 PCI Express four-channel frame grabber with audio capture simultaneously capture four channels of analog NTSC/PAL video and four channels of stereo audio. It can capture raw video frames from each channel at a rate of 120 fps for NTSC and 100 fps for PAL. Four BNC connectors are available on the board’s mounting bracket for connecting external composite video sources and a DB15 connector on the same bracket is used for audio inputs. In addition, a 34-pin header provides an alternative convenient access to all I/O signals on the board. The Model 810 frame grabber is suitable for use in applications that require the capture of multi-channel video/audio in PCI Express form factor, such as video surveillance, law enforcement, and traffic monitoring.

To Learn More:

Contact:Sensoray
Headquarters
: Tigard, OR, USA
Product:
Model 810 PCI Express frame grabber
Key Features: Four composite/S-Video + four stereo audio input channels, 120 fps for NTSC and 100 fps for PAL video, captures raw RGB or YUV video or frames, VB1 support.

What Sensoray says:
View more information on the Model 810 PCI Express frame grabber.
