Matrox Imaging streamlines smart camera setup with new software features

The Matrox Design Assistant 3.0 release of the flowchart-based integrated development environment (IDE) for the Matrox Iris GT smart camera line simplifies design of the user's flowchart and human-machine interface (HMI).

Apr 8th, 2013
Matrox Imaging streamlines smart camera setup with new software features
Matrox Imaging streamlines smart camera setup with new software features

The Matrox Design Assistant 3.0 release of the flowchart-based integrated development environment (IDE) for the Matrox Iris GT smart camera line simplifies design of the user's flowchart and human-machine interface (HMI). Video capture, analysis, location, measurement, reading, verification, communication, and I/O operations, as well as a web-based operator interface are all set up within the IDE. The smart camera software provides more ready-made operator view layouts. An analysis status step consolidates decision making and simplifies flowchart design, while filmstrip views ensure that previously analyzed images are readily available. The software also permits monitoring and controlling multiple smart cameras via a multi-camera HMI application and provides support for PROFINET communication, which allows for direct interfacing to Siemens automation devices.
Matrox Imaging
Dorval, QC, Canada


-- Posted by Vision Systems Design

View More Vision+Automation Products

Locate a vendor or system integrator in our Online Buyer's Guide

---

NEW PRODUCT PRESS RELEASE

Matrox Iris GT smart camera with Design Assistant 3.0 software streamlines application
flowchart and HMI design

Advance replacement and extended warranty options now available for Iris GT

Matrox Imaging has announced Matrox Design Assistant 3.0, the latest release of its flowchart-based integrated development environment (IDE) for the
Matrox Iris GT smart camera line.

The Iris GT smart camera and Design Assistant software bundle has always offered full-featured hardware, an intuitive flowchart-based development environment, and field-proven vision tools. With
Design Assistant 3.0, it’s become even faster and easier for users to design their application’s flowchart and HMI. Plus, Matrox Imaging now offers optional advance replacement and extended warranties for these smart cameras.

Design Assistant 3.0 Highlights
Design Assistant 3.0 smart camera software simplifies and accelerates HMI design with more ready-made operator view layouts. The new analysis status step consolidates decision making and simplifies flowchart design, while filmstrip views ensure that previously analyzed images are close at hand. Release 3.0 also permits monitoring and controlling multiple smart cameras via a multi-camera HMI application and provides support for PROFINET communication, which allows for direct interfacing to Siemens automation devices. This latest version of Design Assistant includes other enhancements that improve productivity and the appearance of the operator interface.

An early access version of Matrox Design Assistant 3.0 has been available since Q3 2012. Its release is scheduled for Q4 2012.

About Matrox Iris GT with Matrox Design Assistant
The Matrox Iris GT smart camera with Matrox Design Assistant is intended for system integrators, machine builders, and OEMs who need to quickly configure and deploy machine vision applications. Matrox Design Assistant is an intuitive, versatile, and extendable integrated development environment (IDE) where applications are created by constructing a flowchart. Video capture, analysis, location, measurement, reading, verification, communication, and I/O operations, as well as a web-based operator interface are all set up within the single IDE.

About Matrox Imaging
Established in 1976, Matrox Imaging is a leading developer of component-level solutions for machine vision, image analysis, medical imaging, and video surveillance. Products include frame grabbers, vision processors, imaging computers, industrial and smart cameras, and application development software. Headquartered in Montreal, Quebec, Canada, Matrox is a privately held company with offices in the United Kingdom, Ireland, Germany, and Hong Kong. For more company information, visit "About Matrox Imaging".

1055 St. Regis Blvd., Dorval, Quebec, H9P 2T4

SOURCE: Matrox Imaging
