Software simplifies automation with stacked, tilted parts

3D-Locate delivers real-time, 3-D position information that enables automation equipment to work with parts including items that are stacked or tilted.

Content Dam Etc Medialib Platform 7 Vision Systems Design Articles Online Exclusive Articles 2010 Global 83249

3D-Locate delivers real-time, 3-D position information that enables automation equipment to work with parts including items that are stacked or tilted for applications such as logistics, robot-guided depalletizing, and precision assembly. The software uses multiple sets of 2-D features found by the PatMax geometric pattern-matching tool to determine an object’s 3-D orientation. It can also use input from other location tools such as SearchMax and PatFlex to help determine part orientation.
Cognex
Natick, MA, USA
www.cognex.com

-- Posted by Carrie Meadows, Vision Systems Design

Find more information on Software

------

PRESS RELEASE

COGNEX OFFERS 3D VISION SOFTWARE

Cognex Corporation (NASDAQ: CGNX) announces 3D-Locate, a library of 3D vision software tools that expands application possibilities in vision-guided robotics, assembly, and inspection.

Cognex 3D-Locate delivers accurate, real-time, three-dimensional position information that enables automation equipment to work with a wider variety of parts, including items that are stacked or tilted. Using 3D-Locate can improve vision performance for challenging applications such as logistics, robot-guided de-palletizing and precision assembly, and it can eliminate the need for expensive mechanical fixtures or measurement devices. Cognex 3D-Locate can also be used in combination with Cognex code reading, gauging, and inspection tools.

Robust 3D Location

Cognex 3D-Locate uses multiple sets of two-dimensional features found by Cognex’s patented geometric pattern matching tool, PatMax®, to determine an object’s precise three-dimensional orientation. PatMax tolerates non-uniform lighting and remains reliable even when patterns are partly covered, ensuring accurate part location even in the most challenging settings and conditions. Cognex 3D-Locate can also use input from other Cognex location tools such as SearchMax and PatFlex to help determine part orientation.

Application performance is enhanced by high-precision Cognex calibration tools that adjust for optical distortion and camera position, and synchronize cameras with moving elements like robot grippers—key to the success of any 3D application. PC-based 3D-Locate can handle high throughput applications, and users have the option to choose from a wide range of industrial cameras.

“Many 3D vision packages fail to meet customer expectations in the field because the systems cannot deliver reliable, repeatable results,” said Markku Jaaskelainen, Executive Vice President and Business Unit Manager for Vision Software. “With 3D-Locate, Cognex has leveraged more than a decade of experience in 3D applications to create a robust, general purpose tool that can be used for a wide variety of applications.”

3D-Locate can be used in:

· Single camera applications that need more information than a 2D approach can offer

· Robot-mounted single or stereo camera guidance systems

· Work cells with multiple fixed-mount cameras, to eliminate mechanical fixtures

· Dimensioning, sorting and picking applications on conveyor lines

3D-Locate is available as part of the Cognex CVL software library. For more information on 3D-Locate, download a data sheet at www.cognex.com/3D.
