New FRAMOS sensor module features IMX530 image sensor and MIPI CSI-2 conversion

Feb. 25, 2020
An updated driver for NVIDIA Jetson TX2 and AGX Xavier development boards has also been released.

The FSM-IMX530 sensor module from FRAMOS incorporates the Sony IMX530 global shutter CMOS image sensor into a sensor module with SLVS and SLVS-EC interfaces. Up to 8 lanes of 5 Gbps each via the SLVS-EC interface makes possible a maximum 98 fps capture rate at 5320 x 4600 resolution. The 28 x 28 mm sensor module also features 2.74 µm pixel size and 74% quantum efficiency (QE).

The FRAMOS sensor adapter connects to the FSM-IMX530 and converts SLVS data to MIPI CSI-2. A 60-pin Hirose connector provides a direct link to Systems-on-Chip (SoCs). A FRAMOS software pack update on Jetpack 4.2 and Linux for Tegra (L4T) version 32.2 for the NVIDIA Jetson TX2 and AGX Xavier boards is included in sensor module development kits.


To Learn More:

Contact: FRAMOS
Headquarters: Taufkirchen, Germany
Product: FSM-IMX530 sensor module
Key Features: Sony IMX530 image sensor, 2.74 µm pixel, 74% QE, SLVS and SLVS-EC Interfaces, maximum 98 fps capture rate at 5320 x 4600 resolution.

What FRAMOS says:
View more information on the FSM-IMX530 sensor module.
