ULIS samples infrared sensor array based on amorphous silicon technology
The Micro80P, an 80 x 80 small-pixel-pitch, high-sensitivity thermal sensor array based on amorphous silicon (a-Si) microbolometer technology, is available for sampling from ULIS.
The Micro80P, an 80 x 80 small-pixel-pitch, high-sensitivity thermal sensor array based onamorphous silicon (a-Si) microbolometer technology, is available for sampling. It is designed to be used in next-generation motion detection systems, building energy-diagnostics tools, and other thermal equipment. The infrared (IR) sensor array can be used in two ways: to produce data as an image for low-end imaging applications, so that users can see what is being measured; and to provide image-free data for thermal detection applications, such as automated building energy management, security access, or counting people.
-- Posted byVision Systems Design
View More Vision+Automation Products
Locate a vendor or system integrator in our Online Buyer's Guide
NEW PRODUCT PRESS RELEASE
Infrared sensor specialist ULIS makes new Micro80P available for sampling
IR thermal sensor array Micro80P will bring new capabilities to building diagnostics and automation equipment used in energy efficiency management
ULIS will showcase Micro80P at Sensor and Test in Nuremburg, Germany, May 14 - 16, 2013 at stand 12502 and present a technical paper on low power consumption thermal sensor arrays.
Veurey-Voroize, France - ULIS, a manufacturer of high quality infrared (IR) imaging sensors for thermography, security and surveillance, automotive and military applications, announces today that Micro80P, its first 80x80 small pixel pitch high-sensitivity thermal sensor array, is available for sampling.
Selected customers have started testing the first units of Micro80P, which is based on amorphous silicon (a-Si) a microbolometer technology industry proven for its reliability. Micro80P aims at improving next-generation motion detection systems and increasing the measurement accuracy of building energy diagnostic tools, such as spot thermometers and other commercial thermal equipment, thereby enabling users to obtain more reliable data.
“ULIS’ Micro80P is designed to fill a capability gap in existing low resolution thermal detection sensors,” said Emmanuel Bercier, product line manager at ULIS. “It delivers data that goes several steps beyond the simple binary ‘yes/no’ response provided by today’s single or quad element thermal detection sensors that are used in, for example, motion detectors. In addition to detecting motion, ULIS’ higher spatial resolution 80x80 pixel thermal sensor array can also count, localize and classify objects or human activity. This means Micro80P can be used to regulate heating/air conditioning by informing the system about the number of people present in a room or other elements present that could impact air temperature, such as the walls. Initial feedback from customers who are sampling Micro80P has been positive. We will be ready to launch Micro80P by mid-year.”
Micro80P extends ULIS’ product portfolio from its high-resolution, high-sensitivity thermal imaging sensors used in thermography, security and surveillance, transportation and military applications to an entry level product at the upper end of thermal detection sensors. Consequently, Micro80P can be used in either of two ways: one will be to produce data in the form of an image for low-end imaging applications, like spot thermometers, so that users can see what is being measured. This is not the case today. The other will be to provide image-free data for thermal detection applications, such as automated building energy management, security access or people counting.
ULIS will display Micro80P at stand 12502 during the Sensor and Test exhibition, May 15 - 16, 2013 in Nuremburg, Germany.
The team will also present a technical paper on performance enhancements in next-generation thermal sensor arrays entitled: “Low power consumption infrared thermal sensor arrays for smart detection and thermal imaging applications.” The presentation will focus on the Readout Integrated Circuit (ROIC) architecture of an 80x80 format sensor, which embeds the latest on-chip innovation, such as low power consumption management, using an I2C standard interface. Vacuum packaging technology improvements, such as Pixel Level Packaging (PLP), will be covered.
ULIS, a subsidiary of Sofradir and GE Equity, specializes in the design and manufacture of high quality infrared imaging sensors for thermography, security and surveillance, automotive and military applications. It enables makers of consumer electronics and infrared equipment to produce low weight, low power consumption and cost-effective thermal cameras in large volume.
ULIS ranks among the top three for uncooled infrared (IR) sensors delivered. It is the only company out of the top three to use amorphous silicon-based technology that provides unusually high uniformity, a key parameter for high-resolution imaging. Due to its amorphous silicon technology, a robust and reliable semiconductor material proven for its industrial production capacity, the company also achieves large-scale production, which is enabling it to meet the growing demand from existing commercial and emerging markets.
ULIS is located in Veurey-Voroize, near Grenoble and employs 140 people.
