Edmund Optics' new multi-element tube system designed to simplify prototyping

The TECHSPEC Multi-Element Tube System released by Edmund Optics combines outer tubes with M29 threads, inner single and pair optic mounts also with M29 threads, and a selection of mix-and-match components to allow for highly adjustable optics designs and to aid with prototyping.

Apr 25th, 2019
Content Dam Vsd Online Articles 2019 04 Edmund Optics Multi Tube Element System

The TECHSPEC Multi-Element Tube System released by Edmund Optics combines outer tubes with M29 threads, inner single and pair optic mounts also with M29 threads, and a selection of mix-and-match components to allow for highly adjustable optics designs and to aid with prototyping.

The system accommodates circular optics with diameters from 5 mm to 25.4 mm and edge thicknesses up to 17 nm. System lengths can range from 15 mm to 100 mm. System components include spacer rings and tubes, and inner apertures.

To Learn More:

Contact:Edmund Optics
Headquarters: Barrington, NJ, USA
Product:TECHSPEC Multi-Element Tube System
Key Features:Mix-and-match components to allow for highly adjustable optics designs and to aid with prototyping.

What Edmund Optics says:
View more information on the TECHSPEC Multi-Element Tube System.
