CCD cameras come in 1- and 2- Mpixel models

JANUARY 26, 2010--The new SX cameras feature Kodak's progressive-scan, interline CCD image sensors with Quad-Tap technology.

Jan 26th, 2010
Content Dam Etc Medialib Platform 7 Vision Systems Design Articles Online Exclusive Articles 2010 Global 58705

JANUARY 26, 2010--The new SX cameras feature Kodak's progressive-scan, interline CCD image sensors with Quad-Tap technology. With a resolution of 1024 × 1024 pixels, the 1-Mpixel camera can achieve speeds of 120 frame/s depending upon the number of output taps used. The 2-Mpixel camera offers horizontal and vertical resolutions of 1600 × 1200 pixels, respectively, and can achieve speeds up to 68 frames/s. All SX cameras measure 52 × 52 × 54 mm and feature robust electronics that withstand various application environments. The devices use the Camera Link Base interface.
Baumer
Southington, CT, USA
www.baumer.com/cameras

-- Posted by Carrie Meadows, Vision Systems Design

Find more information on Image Sensors

------

PRESS RELEASE

BAUMER SX CAMERAS ALLOW FASTER FRAME RATES
AT HIGHER RESOLUTIONS

Cameras Feature Kodak Quad-Tap CCD Image Sensors


Southington, Conn. — For industrial vision applications requiring 1 to 2 megapixel resolutions at frame rates up to 120 fps, Baumer has introduced the new SX Cameras that feature Kodak’s progressive scan, interline CCD image sensors with Quad-Tap technology.

Offering resolutions of 1024 x 1024 pixels, the one megapixel camera can achieve speeds of 120 fps depending upon the number of output taps used. The two megapixel camera offers horizontal and vertical resolutions of 1600 x 1200 pixels respectively, and can achieve speeds up to 68 fps. All SX Cameras are compact -- measuring just 52 x 52 x 54 mm, and feature robust electronics that withstand a range of application environments.

The digital interface for Baumer SX Cameras is CameraLink Base. This industrial interface provides high throughput of data with little latency time. To simplify the integration of these cameras into existing operating software, Baumer provides a modern SDK containing Baumer-GAPI – a generic API, many code examples, and programming documentation.

For more information on the Baumer’s new SX Cameras, contact Baumer at (800) 937-9336, http://www.baumer.com/cameras or via e-mail at MAILTO:sales.us@baumergroup.com.

The Baumer Group is a leading international manufacturer of sensors and system solutions for factory and process automation. In 2009 the innovative family-owned company employs about 2,000 people worldwide in 35 locations and 18 countries. The long lasting success is built on high customer focus as well as the innovative and diversified product range of the five product segments Sensor Solutions, Motion Control, Vision Technologies, Process Instrumentation, and Gluing Systems.

Baumer Ltd.
860-228-8056
