EPIX releases dual composite video PCIe frame grabber

The PIXCI SV7 frame grabber has two BNC jacks for composite video cameras (NTSC, RS-170, PAL or CCIR).

Content Dam Etc Medialib New Lib Vision Systems Design Online Articles 2010 07 36988

PRESS RELEASE

The PIXCI SV7 frame grabber has two BNC jacks for composite video cameras (NTSC, RS-170, PAL or CCIR). The two inputs are independent, allowing capture of different resolution or format. Digitized video is transferred to the PCI Express bus at video rate. Images may be transferred, at full or reduced frame rates, to computer memory for processing and/or analysis by the host computer’s processor(s), or to other targets on the PCI Express bus.

Programmable gain, hue, brightness, saturation, and contrast adjustments can condition the video signal. SMA connectors provide TTL Trigger In and Strobe Out. Up to 4 PIXCI SV7 boards, in one computer, can capture at the same time from up to 8 video sources.

The XCAP-Lite imaging program, provided at no charge with the PIXCI SV7, provides independent Capture & Adjust Dialogs for each of the two inputs. The PIXCI SV7 frame grabber, with XCAP-Lite software, is $395.00.

Visit EPIX's product page.


PRODUCT INFORMATION
Charles Dijak
EPIX, Inc.
381 Lexington Drive
Buffalo Grove, IL 60089
Tel: 847.465.1818
Fax: 847.465.1919
cad@epixinc.com
www.epixinc.com
