ON Semi's 2.3- and 5.3-Mpixel image sensors enable intelligent transportation monitoring

ON Semiconductor (which acquired Cypress Semiconductor Corp.'s Image Sensor Business Unit) offers extensions to the VITA family of image sensors -- the 2.3-megapixel VITA 2000 and the 5.3-megapixel VITA 5000.

Apr 25th, 2011
Content Dam Vsd Online Articles 2011 04 Vsdprodonsemi042511

NEW PRODUCT PRESS RELEASE

ON Semiconductor (which acquired Cypress Semiconductor Corp.'s Image Sensor Business Unit earlier in 2011; Phoenix, AZ, USA) offers extensions to the VITA family of image sensors -- the 2.3-megapixel VITA 2000 and the 5.3-megapixel VITA 5000. They are ideal for machine vision, high-end security, 2D barcode, surveillance, and other intelligent transportation applications.

The image sensors offer an array of sophisticated features, including pipelined and triggered global shutter modes and a conventional rolling shutter mode, speeds of up to 92 frames per second (FPS) for VITA 2000 and 75 FPS for VITA 5000, and 10-bit analog-to-digital converters (ADCs), with either parallel outputs or serialized outputs up to 620 Mbps. They feature programmable registers to control different operating modes, configurable over a standard SPI interface.

The VITA 2000 can provide output in two standard formats: HD (1920 x 1080), which is typically used in the security market; and 4:3 (1600 x 1200), popular in the machine vision market. The sensor array has a standard 2/3” optical format lens. It offers four parallel LVDS channels.

The VITA 5000 has a standard 1” optical format with monochrome or color digital output. The pipelined global shutter capability enables exposure during read-out to reduce motion blur. The sensor also works in a rolling shutter mode with Correlated Double Sampling (CDS) to reduce noise and increase dynamic range. It offers eight parallel LVDS channels.

SOURCE: ON Semiconductor
