Module compensates for unwanted motion

The Enhanced Throughput Module (ETM) is designed to improve positioning performance of high-dynamic motion systems.

Feb 10th, 2010
Content Dam Etc Medialib Platform 7 Vision Systems Design Articles Online Exclusive Articles 2010 Global 31734

The Enhanced Throughput Module (ETM) is designed to improve positioning performance of high-dynamic motion systems by directly measuring unwanted motion of the machine base and communicating it back to the controller for compensation. By working in concert with the company's controllers, the ETM allows the servo system to compensate for dynamic motion artifacts and execute the desired motion path.
Aerotech
Pittsburgh, PA, USA
www.aerotech.com


-- Posted by Carrie Meadows, Vision Systems Design

Find information on Factory Automation

------

PRESS RELEASE

Aerotech’s Enhanced Throughput Module (ETM) Improves Positioning Performance of High-Dynamic Motion Systems

* Significantly improve move-and-settle time and contouring performance

* Increase throughput of existing and new machines

* Greatly reduce undesirable effects of frame motion on the servo system

* Compatible with all current Aerotech controllers

Aerotech’s Enhanced Throughput Module (ETM) improves positioning performance of high-dynamic motion systems by directly measuring unwanted motion of the machine base and communicating it back to the controller for compensation. By working in concert with Aerotech controllers, the ETM allows the servo system to compensate for dynamic motion artifacts and to do a superior job of executing the desired motion path.

Unwanted base motion typically occurs because the force applied to accelerate the stage reacts against the machine frame. The machine frame responds with an oscillation that can extend over hundreds of milliseconds. Fine positioning or accurate high-dynamic motion requires that the controller wait for this oscillation to subside before continuing with the process. This forces the controller to wait or causes inaccurate motion, either of which reduces productivity. The most appropriate solution is an optimized frame and machine-base design, but in many circumstances this isn’t practical or is prohibitively expensive.

The Aerotech ETM provides a low-cost solution for improving the productivity of new and existing equipment with easy installation and no changes to existing mechanical hardware.

For further information, please contact Steve McLane at 412-967-6854 (direct), or via e-mail at smclane@aerotech.com. In addition, the ETM data sheet is available at http://www.aerotech.com/products/accessories/etm.html.
