Matrox Design Assistant 2.3 smart camera software offers bead inspection tool and simplified fixturing

Matrox Imaging has announced Matrox Design Assistant 2.3, the latest release of its integrated development environment (IDE) for the Matrox Iris GT smart camera.

Sep 3rd, 2010
Content Dam Etc Medialib New Lib Vision Systems Design Online Articles 2010 09 7474

PRESS RELEASE

Matrox Imaging (Dorval, QC, Canada) has announced Matrox Design Assistant 2.3, the latest release of its integrated development environment (IDE) for the Matrox Iris GT smart camera. Design Assistant 2.3 offers many new features and enhancements including a bead inspection tool and simplified fixturing, as well as support for Microsoft Windows 7. This release is a follow-on to Design Assistant 2.2, which enabled the use of the built-in keyboard, video (monitor) and mouse (KVM) capabilities.

Design Assistant 2.3’s bead tool inspects material applied as a continuous sinuous bead, such as adhesives and sealants, and identifies discrepancies in application length, placement and width, as well as discontinuities. The allowable bead width, offset, gap and overall acceptance measure can be adjusted to meet specific inspection criteria.

For applications where mechanical fixturing of parts is impractical, Design Assistant 2.3’s simplified fixturing automatically positions (i.e., returns the x-y coordinate and angle for) the region of interest (ROI) for a measurement or reading tool using the results from a locating tool.

This latest version of Design Assistant offers improved project switching capabilities, support for MODBUS master mode for controlling automation devices, and simplified flowchart branching using the switch-case element.

The Design Assistant 2.3 IDE can now be installed and used on 32/64-bit Windows 7.

About Matrox Design Assistant
Matrox Design Assistant is an intuitive, versatile and extendable integrated development environment (IDE) that uses an intuitive flowchart-based methodology to create machine vision applications. Video capture, analysis, location, measurement, reading, verification, communication and I/O operations, as well as a web-based operator interface are all set up within this single IDE.

About Matrox Imaging
Established in 1976, Matrox Imaging is a leading developer of component-level solutions for machine vision, image analysis, medical imaging, and video surveillance. Products include frame grabbers, vision processors, imaging computers, industrial and smart cameras, and application development software. Headquartered in Montreal, Quebec, Canada, Matrox is a privately held company with offices in the United Kingdom, Ireland, Germany, and Hong Kong.

-- Posted by Vision Systems Design
