e2v sensors capture images from space

Jan. 17, 2013
The Centre National d'Etudes Spatiales (CNES) Earth observation satellite Pléiades 1B has captured its first images using e2v's (Chelmsford, UK) imaging sensors.

The Centre National d'Etudes Spatiales (CNES) Earth observation satellite Pléiades 1B has captured its first images usinge2v's (Chelmsford, UK) imaging sensors.

Two types of e2v sensors (for panchromatic and multispectral imaging) equip the satellites optical imaging instrument; these were selected by Thales Alenia Space, who is providing the HR instrument to Astrium, developed under CNES contract.

Pléiades 1B has been designed to provide dual use optical observation coverage with a 70-centimeter resolution. It was launched into space from French Guiana on 30 November 2012 and has accompanied its twin, Pléiades 1A, which was launched into space in December 2011.

The Astrium division of EADS built both Pléiades satellites for the French CNES space agency for use by the French and Spanish defense ministries, civil institutions, and private users. They are based on smaller, cheaper, more agile platforms than their predecessors – the Spot satellite series.

The 200kg, optical imaging instrument on board Pléiades is equipped with a panchromatic and multispectral focal plane. Five e2v CCD98-50 imaging sensors equip the panchromatic focal plane; the sensors have 6,000 pixels each (giving 30,000 pixels per line), are back-thinned to improve sensitivity and have Time Delay Integration (TDI) functionality to enable them to capture high resolution images (70cm on-ground resolution).

The multispectral focal plane is made up of five e2v AT71554 imaging sensors. These imaging sensors cover four spectral bands, made up of 1,500 pixels each, with each spectral band providing 7,500 pixels once installed in the focal plane.

Related articles from Vision Systems Design you might also find of interest.

1.Satellite returns first images of the Earth

CCD imaging sensors on board the SPOT 6 Earth observation satellite have successfully returned their first images.

2.Satellite imager captures perfect picture of a blue Moon

Europe's latest weather satellite got a glimpse of the Moon before it disappeared from view behind Earth on Friday last week.

3.Scientists awarded grant to develop lake surveillance system

A consortium of scientists from six UK universities and research institutes has been awarded a £2.5m grant to create the world's first satellite-based global lake surveillance system, to monitor how lakes and reservoirs are being affected by environmental change.

Vision Systems Design magazine and e-newsletter subscriptions are free to qualified professionals. To subscribe, please complete the formhere.

-- Dave Wilson, Senior Editor,Vision Systems Design
