Z-LASER introduces laser and camera-based 3D measurement system

Z-LASER’s Z3D-Control is a laser and camera based 3D measurement and control system designed for standardized 3D measurements and projections in various industries.

Sep 2nd, 2014
Content Dam Vsd En Articles 2014 09 Z Laser Introduces Laser And Camera Based 3d Measurement System Leftcolumn Article Thumbnailimage File

Z-LASER’s Z3D-Control is a laser and camera based 3D measurement and control system designed for standardized 3D measurements and projections in various industries. The Z3D-Control consists of a pair of GigE cameras and a 638 nm red laser light source with an optional 450 nm blue laser light source also available. The system has a freely-adjustable measuring range, real-time tracking of location position, and proprietary Z3D software, with GEOMAGIC software also available as an option. In addition, the Z3D-Control system enables 3D measurements without reference targets, projection of 3D contours for assembly aid, target-actual comparison between CAD data and work piece, and display of target-actual differences through laser projection.

To Learn More:

Contact:Z-LASER
Headquarters: Freiburg, Germany
Product: Z3D-Control system
Key Features: Two GigE cameras, 638 nm red laser light source, 50 Hz refresh rate, IP 65 enclosure, proprietary software.

What Z-LASER says:
View more information on the Z3D-Control system.
