Imaging software checks pantographs for defects

Dec. 13, 2012
Engineers at the Italian firm Henesis (Parma, Italy) have developed a software tool to automatically monitor train pantographs.

Engineers at the Italian firm Henesis (Parma, Italy) have developed a software tool to automatically monitor train pantographs.

A pantograph is an apparatus mounted on the roof of an electric train to collect power through contact with an overhead catenary wire. Typically a single wire is used, with the return current running through the track.

The so-called "Pantobot" software can process images acquired from trains crossing remote monitoring stations at full speed.

It allows real-time remote classification of the pantograph model from the images and the recognition of the contact material on the contact bars, such as graphite and copper.

Other software modules in the software perform real time analysis on the state of the pantographs, enabling operators to analyze any excessive wear of the contact bars and geometrical deformations.

In addition to automating the inspection task, the software can also generate alerts to operators, making their task easier and reducing their workload.

More information on the software can be found here.

Related articles from Vision Systems Design that you might also be interested in.

1. Radar system spots luggage on the tracks

Engineers at the Universite Lille Nord de France (Lille, France) have developed an ultrawideband radar system that could be fitted in train stations to quickly identify objects that have fallen on the tracks, preventing serious accidents and reducing delays.

2. Mobile robots inspect rails, consumer goods

Coupling the latest technological advances in robotics with audio, visual, and tactile feedback systems and software is paving the way for the next generation of mobile robots, some of which have been developed to inspect railroad switches.

3. Vision system tracks trouble with trains

Developing imaging systems for the transportation industry requires modification of off-the-shelf machine-vision components and customized software.

4. Software detects weeds near the tracks

Researchers at the Faculty of Electrical Engineering and Computing at the University of Zagreb (Zagreb, Croatia) have developed software to detect and analyze the vegetation alongside railroad tracks.

Vision Systems Design magazine and e-newsletter subscriptions are free to qualified professionals. To subscribe, please complete the form here.

-- Dave Wilson, Senior Editor, Vision Systems Design
